10.6.2 Add-on Elements
Pressure Sensor
The installation of the pressure sensor will be made factory-side. Its actual position can be either at the side
(left or right) or on top. Please refer to the assembly instructions „Pressure Sensors 97PA-21x-xxx“ for addi-
tional information.
Pos.
Description
1
Pressure sensor mounted on top of the spray valve
2
Pressure sensor mounted at the right side of the spray valve
Heating Plate
The heating plate (3) will be mounted factory-side. Its actual position will be at the side (left / right). Please
see the description „Heating and Accessories“ for additional information.
3
2
1
3
