WAM TE - Page 76

TE
1
CON.109.--.T.4L-NL
05.16
-
-
-
-
ØT
048
kg
060
kg
114
kg
168
kg
ØA ØB D n° Code Code Code Code
070
95 M10 4
XAV070T0481 1.7 XAV070T0601 2.5 / /
085
110 M12 4
/ XAV085T0601 3.1 / /
100
130 M16 4
/ XAV100T0601 4.5 / /
100
155 M16 4
/ / XAV100T1141 15.4 /
125
155 M16 6
/ / XAV125T1141 13.2 /
160
200 M20 6
/ / XAV160T1141 18 XAV160T1681 33
190
235 M24 6
/ / XAV190T1141 23.5 XAV190T1681 36.5
Code øA B C øD øE
F
øT kg
Ø N°
XAT125T1681
125 41 31 105 168 M 16 6 168 4.3
SHAFTCOUPLINGS
WELLENVERBINDUNGEN
ACCOUPLEMENTS
ASKOPPELINGEN
Flight tube diameter
Durchmesser Rohr mit Wendel
Diamétre tube porte-spire
Vluchtbuis diameter
XAV-XAT
XAT
XAV
18
