1.0 GENERAL INFORMATION
VL
2
VAL.130.--.M.EN Issue: A1
09.16
3
Symbol
representation
Symbol description
Danger sign: indicates danger of electric shock caused by the presence of powered
components inside the junction box or control panel.
Obligation: read this Manual before carrying out any action on the valve concerned.
Forbidden: indicates that it is forbidden to lubricate or adjust moving parts.
Danger: indicates danger of serious injury to limbs if the internal moving parts of the
valve are exposed. Before carrying out inspection operations, isolate the valve con-
cerned from the electrical energy sources.
Information: indicates the direction of rotation of the electric motor.
Obligation: indicates the hooking points for lifting of the valve concerned.
Forbidden: indicates it is forbidden to introduce hands into the valve.
List of safety and information symbols
