WarmFlow Utility U90HE - 4.5 Boiler Component Overviews

4.5 Components
4.5.1 B-Series Boilerhouse – Casing Components & Key Components
1
4
5
6
2
3
Page 10
1. Boiler Assembly
2. Top Front Casing (removable)
3. Top Rear Casing (removable)
4. Sides & Rear Casing
5. Front Casing (removable)
6. Bottom Front Casing
1. Heat Exchanger
2. Condensing Unit
3. Auto Air Vent
4. Service Door
5. ‘Dual-Safe’ Thermostat
6. Heat Exchanger Baffles
7. Service Door
8. Service Door Cover
9. Condensate Trap
10. Riello RDB 2.2 Burner
11. Heating Flow Connection
12. Heating Return Connection
