WarmFlow Utility U90HE - 7.2 Two Pipe System; 7.3 De-aerator System Configuration

Page 48
7.2 Two Pipe System
Total Maximum Pipe Length (m)
Head H(m)
0.0
0.5
1.0
1.5
2.0
3.0
3.5
ID 8mm
35
30
25
20
15
8
6
ID 10mm
100
100
100
90
70
30
20
7.3 De-aerator System
For maximum pipe length and lift contact de-aerator manufacturer.
