INTRODUCTION
Technical Specifications
Supply Voltage 120-240V, AC +10/ -15%, 50/60Hz
Maximum Switch Load 15A
Note: This product is not designed to be used with any inductive load.
GFCI Class A GFCI with 5mA trip level
UL Listed Standards UL873 & UL943
Temperature Display Range +32°F to 122°F (0°C to + 50°C )
Operating Temperature +32°F to 122°F (0°C to + 50°C )
Storage Temperature -4°F to + 140F (-20°C to + 60°C)
Floor sensor Type NTC (10K)
4.41”
1.97”
3.54”
1.18”
1.65”
1.73”
Dimensions (inch)
Dimensions in inches
