IMPORTANT
Ensure that multi strand wires are fully inserted into twist-on wire connectors (wire nuts) and secured
tightly. Any loose strands should be trimmed as they could cause a short-circuit.
Mounting the thermostat
1. Close the electrical back box by screwing the front part (already attached to the back module of the
thermostat) onto the rear part installed into the wall.
2. Ensure that the thermostat is straight before tightening completely.
4. Replace the thermostat's front housing;
- align and sit front housing on to hinges,
- push lower half of front housing until you hear a ‘click’.
5. Ensure front housing is securely fixed and insert the retaining screws.
6. Tighten both retaining screws.
Note: Do not obstruct the thermostat’s vents.
INSTALLATION
