©2021 Warn Industries, Inc. WARN® and the WARN logo are trademarks of Warn Industries Inc. 6 100243A1
6. Carefully remove the bumper and place it on a clean stable
surface.
7. Using a T45 Torx driver, un-install the cover plate by
removing the ve bolts attaching it to the bumper.
8. With cover o, use the supplied M8 x 1.25mm hex nuts and
the ve T45 Torx head bolts (just removed) and reinstall back
into the bumper. This step is for cosmetic purposes only.
9. Remove the license plate and license plate cover.
CAUTION
• Always use assistance when moving or lifting heavy parts.
Figure 9
Figure 7
Figure 8
