WARN® INDUSTRIES PAGE 15 72171 Rev A0
29. Install stand to plow support by inserting tab
through slot. See Figure 29 and 30.
30. Install latch assembly to top edge of stand and up
against the side of plow support. See Figure 31.
Figure 29 Install stand, right hand side shown
Figure 30 Install stand slot to plow support tab
Figure 31 Install latch assembly to stand and plow support
Stand Slot
Plow Support
Tab
Assembled
Latch
