19. Transport Dimensions and Weights
19.1 Lifting the in-line engine
Fig 19-1 Lifting inline engines (DAAE016050a)
Weights without flywheel [ton]H
[mm]
Y
[mm]
X
[mm]
Engine
type
Total
weight
Transport
cradle
Lifting
device
Engine
106.7
106.7
6.4
6.4
3.3
3.3
97
97
5050
5050
1520
1520
8330
1)
8350
2)
6L46F
122.7
122.7
6.4
6.4
3.3
3.3
113
113
5350
5350
1720
1720
9380
1)
9430 2)
7L46F
133.7
133.7
6.4
6.4
3.3
3.3
124
124
5350
5350
1720
1720
10200
1)
10250
2)
8L46F
152.9
152.9
9.6
9.6
3.3
3.3
140
140
5350
5350
1720
1720
11020
1)
11070
2)
9L46F
Turbocharger at free end
Turbocharger at flywheel end
1)
2)
Wärtsilä 46F Product Guide - a19 - 1 December 2017 19-1
19. Transport Dimensions and WeightsWärtsilä 46F Product Guide
