19.2 Lifting the V-engine
Fig 19-3 Lifting of V engines (DAAG022525, DAAG022526)
K
[mm]
J
[mm]
I
[mm]
H
[mm]
G
[mm]
F
[mm]
E
[mm]
D
[mm]
C
[mm]
B
[mm]
A
[mm]
Engine type
13610284252451295835~14200~91002300402637652066W12V46F
13311383-60606289~14200~91002300465042252066W14V46F
Weights [ton]Engine type
Total
weigth
Ropes
Lifting
device
Total En-
gine
(±2.5)
Tarpaulin
Trans-
port
cradle
Lifting
tools
Flywheel
Flexible
mounting
Engine
201.12.01.5197.60.29.62.51.19.2175.0W12V46F
242.12.01.5238.60.29.62.51.110.2216.0W14V46F
Wärtsilä 46F Product Guide - a19 - 1 December 2017 19-3
19. Transport Dimensions and WeightsWärtsilä 46F Product Guide
