Fig 19-6 Major spare parts (DAAE029505)

Weight [kg]DescriptionItemWeight [kg]DescriptionItem

4.2Starting valve9615Connecting rod1

12Main bearing shell10211Piston2

-Split gear wheel11932.5Cylinder liner3

111Small intermediate gear121170Cylinder head4

214Large intermediate gear1310Inlet valve5

252Camshaft gear wheel1410.6Exhaust valve6

2.5Piston ring set15142Injection pump7

0.5Piston ring25Injection valve8
