10.
Remove the Filter Cartridge from the filter head as shown.
11.
Screw the Filter Body to the filter head, making sure it’s securely
tightened.
12.
Fit the filter assembly into the machine as follows:
a) Insert the filter assembly back into its cradle, aligning the
two male spigots with the female holes in the cradle
b) Push it firmly until the filter sits snugly and is flush with the
cradle top surface
c) Lock the filter by closing the locking lever until it ‘clicks’ into
place
13.
Reinstall the top cover and insert the two screws at the rear of the
machine that secure it
14.
Turn on the water supply at the isolation point
15.
Reconnect the power lead and insert it into the
rear of the machine. Turn On the Red Power
Switch. I=ON
