WaterLogic CUBE FIREWALL - MODEL;PART DESIGNATIONS; CUBE Model Information; SPECIFICATIONS; Water Temperature and Capacity

CUBE Manual Page 8 - Revision: 5-24-2017
MODEL/PART DESIGNATIONS
BRAND NAME DESCRIPTION
CUBE Water Treatment System
Waterlogic CUBE – Ambient, Cold, Hot, and Extra Hot
Model F-FWCU1-M-HCA-TT-SB-IN1
Serial Number Prefix: 81
SPECIFICATIONS
ITEM
Water ¼” Quick Connect
Cold Water Temperature
Cold Water Temperature – Factory Set Point 41°F - 5°C
(Adjustable) 34° - 54° F. (1.1° - 12.2°C)
Cold Water Capacity 1.4 Liter Cold Tank
Hot Water Temperature
Factory Set Point 187°F (86C°)
Programmable 158° - 203°F (70° - 95°C)
Hot Water Capacity 1.3 Liter Hot Tank
Extra Hot Water Temperature Extra Hot Water Temperature – Factory Set Point 203°F (95C°)
Hot Tank Manual Reset Overload 221°F (105°C)
Maximum Working Pressure 60 psi (414 kPa) – Use Pressure Regulator
Environmental Temperature
35° - 100°F (2° - 37°C)
Refrigerant Gas R134a – 1.94 oz. (55 grams) - Hi (280 psi) Low (90 psi)
R134a Pressures High (230 psi), Low (90 psi)
