The Cube Technical Manual - Version 1, May 2014
34 35
Wetted Parts List
Hot, Cold and Sparkling
N° Part Description
30 Silicon Tube 5/16" for hot water
31 JG End Stop 1/4"
32 JG LLD PE Tube - Blue O.D.1/4"
33 JG Equal Tee Connector 1/4"
34 JG 1/4" STOPPER JG UK
35 JG Equal Tee Connector 1/4"
36 JG LLD PE Tube - Blue O.D.1/4"
37 JG LLD PE Tube - Blue O.D.1/4"
38 Solenoid Valve 24 DC (Single Spring Load)
39 JG Equal Tee Connector 1/4"
40 JG Stem Elbow Connector 1/4" * 1/4"
41 JG Equal Tee Connector 1/4"
42 JG LLD PE Tube - Blue O.D.1/4"
43 CBC 1 Micron 10" Filter Ass’y-PD WL Labe
44 Hot & Cold Solenoid Valve 24V- 300mm CUBE
45 5/16-1/4 Reducing Straight Connector
46 JG Equal Elbow Connector 1/4"
47 5/16-1/4 Reducing Straight Connector
48 JG LLD PE Tube - Blue O.D.1/4”
To Next Page
