WL Max Technical Manual - Version 1 - May 2013
N° Part Description
26 EMI Filter
27 Electrical Panel Cover
28 Electrical Case
29 Power Cord
30 Inline CBC Filter
31 JG 1/4" Bulkhead Connector
32 Filter Clip
33 JG 1/4" Elbow
34 JG 1/4" Straight Connector
35 Drain Hose
36 Reservoir Tank Lid
37 Pump
38 Reservoir
39 Thermostat
40 Drain Connection
41 Condenser Grill
42 Condenser Filter
43 Condenser
44 Rubber Feet
45 Fan
46 Fan Motor
47 Compressor
48 Capacitor
49 Relay
50 Compressor Cover
