Fastrack M1306B User Guide
General Presentation
confidential © Page: 21 / 65
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003 November 11, 2006
3.2 External Connections
3.2.1 Connectors
3.2.1.1 Antenna Connector
The antenna connector is a SMA type connector for a 50 RF connection.
SMA connector for
antenna connection
Figure 6: SMA connector for antenna connection
3.2.1.2 Power Supply Connector
The power supply connector is a 4-pin Micro FIT connector for:
external DC Power Supply connection,
GPIOs connection (two General Purpose Input/Output signals available).
1
2
3
4
Figure 7: Power supply connector
