Fastrack M1306B User Guide
Functional Description
confidential © Page: 41 / 65
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003 November 11, 2006
7 Functional Description
7.1 Architecture
Internal Quick
Wireless CPU
®
RS232
Interface
SMA
Audio
Interface
DC / DC
Power
Supply
BOOT
RESET
V+BATTERY
GROUND
Micro - FIT
4 pins
SUB HD
15 pins
VCC
Microphone
Microphone
Speaker
Speaker
VCCRS232
VCC
SIM card
Socket
SIM card
Holder
Operating
Status
FASTRACK M1306B
GPIO[4]
GPIO[5]
VCCRS232
Figure 13: Functional architecture
