Fastrack M1306B User Guide
Using the M1306B Wireless CPU
®
confidential © Page: 33 / 65
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
WM_PRJ_M13_UGD_001 -003 November 11, 2006
5.5 Verify the Received Signal Strength
The Fastrack M1306B establishes a call only if the received signal is sufficiently
strong.
To verify the received signal strength, do the following operations:
• Using a communication software such as Hyperterminal, enter the AT
command
AT+CSQ.
The response returned has the following format:
+CSQ: <rssi>,<ber> with:
•
<rssi> = received signal strength indication,
•
<ber> = channel bit error rate.
• Verify the
<rssi> value returned using the Table 5 below.
Table 5: Values of received signal strength
Value of received signal
strength indication (<rssi>)
Interpretation of the
received signal strength
0 - 10
Insufficient(*)
11 - 31 Sufficient(*)
32 - 98 Not defined
99
No measure available
(*) Based on general observations.
For further information on AT commands, refer to "AT Commands Interface Guide" [7].
5.6 Check the Pin Code Status
To check that the pin code has been entered, use a communication software such as
a Hyperterminal, then enter
AT+CPIN? command.
The table below gives the main responses returned:
Table 6: AT+CPIN Responses
AT+CPIN response (*) Interpretation
+CPIN: READY
Code PIN has been entered
+CPIN: SIM PIN
Code PIN has not been entered
(*)For further information on the other possible responses and their meaning, refer to
"AT Commands Interface Guide" [7].
