3 General Presentation
3.1 Description
Description of the FASTRACK modem M1306B is given in the Figure Below.
Micro-Fit
connector
Sub HD
connector
SMA
connector
LED
Front cap
Back cap
Extractible
SIM card
holder
BACK CAP
SIM card
holder ejector
Figure 4: FASTRACK modem M1306B general description
