WM_PRJ_M13_UGD_001 - 001
20th July 2004
© 2004
All rights reserved
Wavecom Confidential & Proprietary Information
Page: 16 / 55
This document is the sole and exclusive property of WAVECOM. Not to be distributed or divulged
without prior written agreement.
In addition, two holding bridles are provided to tighten the modem on a support.
Holding bridles
Figure 5: FASTRACK modem M1306B holding bridles
3.2 External connections
3.2.1 Connectors
3.2.1.1 Antenna connector
The antenna connector is a SMA type connector for a 50 Ω RF connection.
SMA connector for
antenna connection
Figure 6: SMA connector for antenna connection
