TnP-500 Diagrams
Case Diagram
• TnP-500 Integrated Appliance Tester
• Wavecom Thermal Transfer Printer
• Barcode Scanner
• Keyboard
• IEC Power Cable
• IEC Test Lead (500mm Orange)
• USB A to USB B Interface Cable
• Earth Lead with Alligator Clips (1800mm Black)
• Shockproof Industrial Case (IP67 Rated)
• 1 Roll (500) of White Labels
• 1 Roll of Printing Ribbon
• WinPATS Software License
• 12 Month Calibration Certificate
• 36 Month Conditional Warranty
• User Manual
On/Off Switch
Power Socket (Blue)
IEC Test Socket (Black)
Head Unit
Keyboard
F1 Button
F2Button
F3 Button
LED Indicators
Storage Compartment
(Under Keyboard)
Tag Printer
Barcode Scanner
LCD Screen
Enter Button
AS/NZS 3112 Appliance Test Socket
