Transmission Modes WAVECOM Decoder W74PC, W-PCI/e, W-CODE, W-CLOUD Manual V9.1.0
NAVAREA
NAV
MET
SAR
OCEAN REGION
XIII (Russian Federation)
X
X (Note 4)
POR
XIV (New Zealand)
X
X
X
POR
XV (Chile)
X
X
X
AOR-W
XVI (Peru/USA)
X
X
X
AOR-W
1. X = Full Service now available.
2. IMO has decided that routine broadcasts of navigational warnings and meteorological forecasts will be
made at scheduled times over a single nominated satellite for each NAVAREA/METAREA unscheduled.
Additional information:
See “SAT Settings…” on page 44.
See “SAT System” on page 298.
SAT-M
The SAT-M system carries digital voice and low speed data. The forward direction channels from land
earth stations (LES or CES) to mobile earth stations (SES or MES) are 6 kBaud for NCS and LES TDM and
4 kBaud for LES voice and low speed data.
Parameter
Value
Frequency range
L-Band/C-Band
Operation modes
Inm-M (Forward NCS and LES Msg Chnl)
Forward:
6 kbps DPSK, NCS TDM (LES TDM optional)
8 kbps OQPSK, LES Voice , LES Low Speed Data
Return:
3 kbps DPSK, Slotted Aloha, TDMA,
8 kbps OQPSK SCPC
Required SNR
>15 dB (20 dB recommended)
Input format(s)
IF
In idle mode all mobile stations listen to the NCS (Network Control Station) common TDM channel, which
carries signaling information. When a mobile station identifies its id in a signaling frame it will act on the
commands received from the NCS and in case of a channel assignment message being received tune to
the assigned transmit-receive frequency pair. The forward telex traffic channel (from the LES) is also a
TDM with the same frame structure as the NCS TDM.
The return channels are 3 kBaud Slotted Aloha for MES requests, call acknowledgements and registration
traffic, TDMA for MES response and 4 kBaud OQPSK for MES voice and low speed data.
WAVECOM decodes SAT-M 2.4 kbps fax and data. The decoder will automatically adjust to the modulation
type in use (BPSK or OQPSK).
Additional information:
See “SAT Settings…” on page 44.
See “SAT System” on page 298.
SAT-MINI-M
The SAT-miniM system carries digital voice and low speed data and fax. The forward direction channels
from land earth stations (LES or CES) to mobile earth stations (SES or MES) are 6 kBaud for NCS TDM,
2.8 kBaud for LES voice, low speed data and fax.
