Wavecom W-CODE User Manual

246

Transmission Modes WAVECOM Decoder W74PC, W-PCI/e, W-CODE, W-CLOUD Manual V9.1.0
Mode
Type
Time [s]
Resolution [Pixel x Line]
Notes
24
B/W
24
320 x 240
36
B/W
36
320 x 240
B/W Mode
SC-1 8
B/W
8
128 x 128
SC-1 16
B/W
16
256 x 128
SC-1 32
B/W
32
256 x 256
Wraase
SC-1 24
RGB
24
128 x 128
b
SC-1 48
RGB
48
256 x 128
a
SC-1 96
RGB
96
256 x 256
a
SC-2 30
RGB
30
256 x 128
SC-2 60
RGB
60
256 x 256
SC-2 120
RGB
120
512 x 256
SC-2 180
RGB
180
512 x 256
Notes:
* Not implemented
a Top 16 lines gray scale
b Top 8 lines gray scale
c Similar to original SSTV
d No horizontal sync (start of a new line)
STANAG-4285
STANAG-4285 is specified by the NATO (North Atlantic Treaty Organization) Military Agency for Standardi-
zation in "Characteristics of 1200 / 2400 / 3600 Bits per Second Single Tone Modulators / Demodulators
for HF Radio Links" (16. February 1989).
Parameter
Value
Frequency range
HF
Operation modes
Broadcast/Simplex FEC
Modulation
8-PSK
Center frequency
1800 Hz
Symbol rate
2400 Bd
Receiver settings
DATA, CW, LSB or USB
Input format(s)
AF, IF
The modulation technique used in this mode consists of phase shift keying (8-PSK) of a single tone sub-
carrier of 1800 Hz. The modulation speed (symbol rate) is always 2400 Bd.
Using different M-PSK modulations and FEC (Forward Error Correction) coding rates, serial binary user in-
formation (raw data) accepted at the line side input can be transmitted at different user data rates.
STANAG 4285 single tone waveform has the following characteristics which may be selected from Options
|Frame Format...:
Baud
Rate
User da-
ta rate
(bps)
User data
rate (bps)
FEC coding
rate
Interleaver
No. of unknown
8-phase sym-
bols (User Data)
No. of known 8-
phase symbols
(Channel Probe)
