WAVECOM Decoder W74PC, W-PCI/e, W-CODE, W-CLOUD Manual V9.1.0 First start
23
The WINDOWS elements TOOLBAR, WAVECOM TOOLBAR, LEVEL INDICATOR and SPECTRUM INDI-
CATOR may be moved anywhere in the screen as required. In the View menu the user may show or hide
all window elements. By default, all elements are visible.
Please be aware that the appearance of the GUI will vary depending on the product, software version and
operating system.
Command Line Parameters
You can pass information to the application by adding command line parameters.
The following commands are valid:
/i <ini file name>
The name of the INI file that is located in the same directory as the decoder application. Alternatively a
path may be entered.
/n <card number>
The number of the card to be connected (a value between 1 and 8).
/c <computer>
The name of the computer to be used for the connection
localhost (not case sensitive) or 127.0.0.1 means that you work with cards on the local comput-
er.
Computer name or the IP address plus the port number to connect to another computer. The port
number must be entered on the WAVECOM Server Control screen. If a port number is not provid-
ed, then default port 33233 is used.
/l <speedlimit>
Speed limit of the connection to the server. This attribute is a choice of “9600”, “14400”, “19200”,
“56k”, “64k”, “128k”, “512k”, “1M”, “2M”, “5M”or “10M”. If no /l option is used, the speed is un-
limited.
Examples (for W-CODE):
WCODE.EXE /i config1.ini
WCODE.EXE /i "\configuration\setupAB.ini"
WCODE.EXE /n 2 /c WCODEServer:5800
WCODE.EXE /n 1 /c 192.168.1.12:8080
WCODE.EXE /n 3 /c 192.168.2.5
WCODE.EXE /n 3 /c 192.168.2.5 /l 56k
Default Data and Program Folders (Paths)
To see all folders, select Folder Options in the Control Panel
Enable Show all folders.
Enable Show hidden files, folders and drives
