Alphabot2 for micro:bit User Manual
70 / 76
TRACKER SENSOR
The tracker sensor helps the robot move along the black line on the ground. There are
five detectors at the bottom of the sensor, and the infrared LED light is used to project
infrared light to the ground to detect the deviation of the module relative to the black
line.
In Alphabot2 package:
SensorCalibrated block is used to calibrate the sensor for accurate Min and Max value.
AnalogRead block is used to read original data from infrared tacker sensor.
ReadCalibrated block is used to read the calibrated data
ReadSenorMax block is used to read the Max calibrated value
ReadSensorMin block is used to read the Min calibrated value
ReadLine block is used to get the position of black line in range 0~4000. 0: Robot is
on the extreme left; 2000: Robot is on the center; 4000: Robot is on the extreme right.
