Waveshare Barcode Scanner Module User Manual

Barcode Scanner Module User Manual
25 / 57 Rev1.0 Date:180621
2) Make sure Setting code is enabled, if no, please scanning the setting code
“Open Setting Code Function”
3) Scanning “Modify prefix”code
4) Scanning the data setting code one by one: “4”, “4”, “4”, “1”,
“5”, “4”, “4”, “1”
5) Scanning “Save” Setting code
2. Suffix
Add suffix
Suffix is definable string added after decoding information.
Modify Suffix
The suffix can be modified as same as the Prefix.
Allow Suffix Adding
*Without Suffix
Modify Suffix
