Barcode Scanner Module User Manual
26 / 57 Rev1.0 Date:180621
Example: Modify the Suffix as “DATA”
1) Query the character table to get the HEX of “DATA” are that : “44”,
“41”,”54”, “41”
2) Make sure Setting code is enabled, if no, please scanning the setting code
“Open Setting Code Function”
3) Scanning “Modify prefix”code
4) Scanning the data setting code one by one: “4”, “4”, “4”, “1”,
“5”, “4”, “4”, “1”
5) Scanning “Save” Setting code
3. CODE ID
Add CODE ID
User can use CODE ID to identify different type of barcode. CODE ID is chagnable.
Every CODE ID has one character.
Default CODE ID
Allow Adding CODE ID
*Without CODE ID
