CHAPTER 9 SETUP OUTPUT COMMUNICATIONS 103
Note
SmartSensor Advance Extended Range only works with the Click 112/114/104 cards. It
does not work with the Click 172/174/100 cards.
In standard installations, either the rst or second option will automatically be selected
when you auto-congure an attached Click detector rack card. e rst option will be
selected if you are using a Click 112/114 and the second option will be selected if you are
using a Click 172/174. With version 3.0.2 and later, the default port is set at 2 and the
default format is Z4 - Click 112/114.
e Trigger Speed and Track File options are not used for standard intersection trac
control, but can be used for other applications. e Trigger Speed option will push the
speed of a detection in Channel 1–Alert 1–Zone 1 each time the channel becomes active.
e Track File option will push the range and speed of all detections as a heartbeat mes-
sage.
Specify output minimum duration
is option allows you to specify the minimum output duration in seconds. e minimum
output duration is the minimum amount of time that a channel output will be on, even
if the output conditions are removed. e selected value should meet the timing require-
ments of any device in the system that will be processing channel outputs. e default value
of 0.13 seconds works well for most devices. e minimum value is 0.01 seconds and the
maximum value is 5.00 seconds.
Specify output frequency
is allows you to specify the output frequency of all heartbeat (contact closure & track
le) messages in seconds. e specied value determines the time interval between output
transmissions. e selected value should meet the timing requirements of any device in the
system that will be processing channel outputs. e default value of 0.13 seconds works
well for most devices. e minimum value is 0.01 seconds and the maximum value is 1.00
seconds.
e Undo button returns all Output Communication parameters to the values they had
when the task was started; the OK button sends all the Output Communication param-
eters to the sensor (the settings are not saved to FLASH at this point). Clicking the Cancel
button will cause you to lose any changes and return to the CAZ menu.
