3 Operation Instruction
Digital Video Recorder(DVR)
User Manual
8
Issue V1.0 (2018-06-04)
3 Operation Instruction
3.1 Front panel
Figure 3-1 shows the front panel of DVR. Table 3-1 shows the description of front
panel.
Figure 3-1 Front panel
Table 3-1 Elements of the front panel
NO.
Element
Description
1
POWER
Power indicator, When DVR is operating, the
Power indicator is steady on. When DVR is
shut down, the PWR indicator is turned off.
2
ALARM
Alarm indicator
This indicator flashes when alarm is transmitted
3
REC
Record indicator
This indicator flashes when DVR is recording
4
NET
Net indicator
This indicator flashes when DVR record
5
USB
Supports connection to a USB mouse, a USB
flash drive or USB removable hard disk.
3.2 Rear panel
Figure 3-2 shows the rear panel of 0E-HD4C1TB and the interfaces on it.
