20 Technical data
NOTE
The wall box is not suitable for 3-phase IT networks.
Description Data
Rated current (A)
(configurable connected load values)
16 or 32
Single-phase or 3-phase
The charging station can be configured in 1A increments
Mains voltage (V AC) 230/400 (Europe)
Grid frequency (Hz) 50
Network types TN / TT (single- and 3-phase)
IT (single-phase only)
Split phase (L1+L2, no N)
EMC class Emitted interference: class B (residential, business, commercial areas)
Immunity: residential, business, commercial and industrial areas
Overvoltage category III as per EN 60664
Protection class I
Required protective devices A residual current circuit breaker RCD of type A and line circuit breaker must be
provided on the installation side as appropriate to the country
Integrated protective device DC residual current protection 6mA
Phase rotation Automatic detection of faulty phase sequence
Fixation type Wall and base mounting (permanently connected)
Cable feed Mounted on-wall or in-wall
Power supply conductor cross section Cross section of the connection cable (Cu) taking into account the local require-
ments and standards:
l rigid (min.-max.) 2.5-10 mm
2
l flexible (min.-max.) 2.5-10 mm
2
l flexible (min.-max.) with wire end ferrule: 2.5-10 mm
2
Charging cable Type 2 charging cable: up to 32 A / 400V AC as per EN 62196-1 and EN62196-2
Length: 4.5 m / 7 m
Output voltage (V AC) 230 / 400
Max. charging capacity (kW) In 3-phase operation: 11 or 22 kW
In 1-phase operation: 3.7 or 7.4 kW
Table5: Electrical characteristics
Description Data
Authentication l “Scan & Charge” via QR code
l Webasto ChargeConnect Portal
l Webasto ChargeConnect App
Display RGB-LED, buzzer
Network interfaces l LAN (RJ45) – 10/100 Base-TX
l WLAN 802.11 b/g/n - 54 Mbit/s
Client: 2.4 GHz and 5 GHz
Access Point: 2.4 GHz
l WLAN Hotspot
Transmission function Transmission frequency
(GHz)
Max. transmission line
(max. EIRP) [dBm]
Wi-Fi (2.4 GHz) 2.402 … 2.480 16
Wi-Fi (5 GHz) 5.180 … 5.320
5.500 … 5.700
18
EIRP = Effective Isotropic Radiated Power
dBm = decibel-milliwatts
Communication protocols OCPP 1.6 J (OCPP 2.0 ready), ModBus TCP
External interfaces l Ripple control receiver via floating contact
l Energy management system (EMS) connection
