Webasto Thermo Top Evo 5+ - Connecting Metering Pump; Connecting metering pump

Mercedes Benz C-Class S204, W204, C204 / GLK-Class X204
Ident. No.: 1315959G_EN Status: 31.01.2013 © Webasto Thermo & Comfort SE
28
Connecting Metering Pump
C204, S204 and W204
Degrease adhesive surface for adhesive
base
6.
1 Metering pump
2 10 mm dia. clamp
3 90° moulded hose
4 10 mm dia. clamp
5 Fuel line
6 Cable tie, adhesive base
Connect-
ing meter-
ing pump
X204
Degrease adhesive surface for adhesive
base
2.
1 90° moulded hose, 10 mm dia. clamp
2 Cable tie, adhesive base
3 Fuel line
Connect-
ing meter-
ing pump
80l fuel tank
1
10 mm dia. clamp
2 Fuel line
3 180° moulded hose
Connect-
ing meter-
ing pump
73
1
3
6
2
4
5
74
3
2
1
75
21
3
