Webasto Thermo Top Evo 5+ - Combustion Air; Cutting combustion air pipe to length; Mounting angle bracket; Mounting combustion air pipe

Mercedes Benz C-Class S204, W204, C204 / GLK-Class X204
Ident. No.: 1315959G_EN Status: 31.01.2013 © Webasto Thermo & Comfort SE
35
Combustion Air
Discard section X.
1 Combustion air pipe
a = 480
Cutting
combus-
tion air pipe
to length
1
Perforated bracket
Angling
down per-
forated
bracket
1
Original vehicle bolt
2 Angle bracket
Mounting
angle
bracket
1
Combustion air pipe
Mounting
combus-
tion air pipe
a
1
X
90°
80
1
92
1
2
93
1
