Webasto Thermo Top Evo 5+ - Page 34

Mercedes Benz C-Class S204, W204, C204 / GLK-Class X204
Ident. No.: 1315959G_EN Status: 31.01.2013 © Webasto Thermo & Comfort SE
34
Slide black (sw) rubber isolator 1 onto hose B .
Routing in
engine
compart-
ment
1
Connection piece on heater outlet
2 Align black (sw) rubber isolator
Connec-
tion of
heater out-
let
90
B
1
A
91
1
2
B
