Technical data | 15
5111967A OI-II Webasto Unite 35 / 37
15.4 Technical specifications
This product is compliant with IEC61851-1 (Ed3.0) standard for Mode 3 use.
Electrical Characteristics Webasto Unite MID Webasto Unite Eichrecht
IEC protection class
Class- I
Vehicle inter-
face
Socket Model
Socket TYPE 2 (IEC 62196)
Rated voltage (V AC)
400 V, 3-phase
230 V, 1-phase
Rated current (A AC)
32 A, 3-phase
32 A, 1-phase
Grid frequency (Hz)
50 / 60
Maximum AC charging power (kW)
22 kW, 3-phase
7.4 kW, 1-phase
Idle power consumption (W)
3.5 W
Built-in residual current sensing module
6 mA
Required circuit breaker on AC mains
40 A MCB Type-C
Required leakage current relay on AC Mains (for products not
equipped with RCCB Type A)
40 A – 30 mA RCCB Type-A
Required AC
mains cable
Cross-section of the connecting cable (Cu) taking into
account the local requirements and standards (min.-
max.)
Rigid: 2.5-10 mm
2
Flexible: 2.5-10 mm
2
Flexible with wire end ferrule: 2.5-10 mm
2
Max. external dimension
Ø 18 – 25 mm
Connectivity
Ethernet 10/100 Mbps Ethernet
Wi-Fi Wi-Fi 802.11 a/b/g/n/ac
Wi-Fi specifications
2.4 GHz Band
Standard 802.11b 802.11g 802.11n 802.11n
Modulation DSS, CKK OFDM OFDM OFDM
Data rate 1, 2, 5.5, 11 6, 9, 12, 18, 24, 36, 48, 54 MCS0 - 7 (HT20) MCS0 -7 (HT40)
Channel* CH 1-13 CH 1-13 CH 1-13 CH 1-13
Power (dBm) 13.5 13.5 13.5 13.5
5 GHz Band
Standard 802.11a 802.11n/ac 802.11n/ac 802.11n/ac
Modulation DSS, CKK OFDM OFDM OFDM
Data rate 6, 9, 12, 18, 24, 36, 48, 54 MCS0 - 9 (HT20) MCS0 - 9 (HT40) MCS0 -9 (HT40)
Channel* CH 36-64 / CH 100-165 CH 36-64 / CH 100-165 CH 38-62 / CH 100-159 CH 42-58 / CH 100-155
Power (dBm) 14 14 14 14
Other features (Connected models)
Diagnostics Diagnostics over OCPP
WebconfigUI
Software update Remote software update over OCPP
WebconfigUI update
Remote software update with server
Authorization
RFID ISO-14443A/B and ISO-15693
Mechanical specifications
Material Plastic
Product size 315 mm (Width) x 460 mm (Height) x 135 mm (Depth)
Dimensions (with package) 400 mm (Width) x 530 mm (Height) x 240 mm (Depth)
Product weight 5 kg
