CR5 13
Starting
Bring the gas lever into full-throttle position.
Check the hydraulic oil level when the machine is at operating
temperature. The correct oil level is reached when the oil is in
the middle of the view glass.
Tighten the screws (1) of the attachment plates (2) with a
torque of 310 NM.
Checking the hydraulic uid level
Mounting the attachment plates
Mounting the Poly pad
Fasten the Poly pad with holder, screws, spring-lock washers
and nuts on the base plate front and rear.
Ensure that the Poly pad rests under the base plate.
Slowly tighten the handle (1) of the reversing starter (2) until
resistance is noticeable.
Allow the handle (1) to glide back into the initial position, and
then forcefully and completely pull it through with both hands.
Allow the engine warm up for a few minutes.
If ambient temperatures are below minus 5 degrees
Celsius comply with the instructions in the operating
manual provided by the engine manufacturer.
1
2
1
2
