Weber mt CR 8 - Machine Component Identification; Overall View of CR 8

14
1
2
3
4
5
6
7
8
9
10
11
Operating positions on the machine
Overall view CR 8
1 Base plate with exciter
2 Mounting bracket
3 Gas lever
4 Handle
5 Guide bar
6 Lifting ring
7 Maintenance cover
8 Engine (no image)
9 Key switch
10* Start module
11** Compaction control system Compatrol 2.0
Figure 1
* Only units equipped with COMPATROL 2.0 compaction control.
* Figure shows the start module MS 25 (MDM / Compatrol 2.0).
