MS 25 & 35 (CR 8 MDM & CCD)
1 Operational status indicator
(LED)
This indicator signals that the ignition of the machine is
switched on. It comes on as soon as the key switch (5)
is set to position “1”.
2 Oil pressure indicator (LED) This indicator warns of insu󰀩cient oil pressure.
Shut down the machine immediately when this indicator
comes on. The engine is switched o󰀨 automatically.
3 Charge level indicator (LED) This indicator comes on if the charging current supply to the
starter battery is insu󰀩cient. While operation of the machine
can resume, the cause of the insu󰀩cient charging current
supply must be identied and rectied.
4 Operating hours counter This eld shows the operating hours completed by
the machine.
The counter will show the remaining time until the next
scheduled maintenance for the rst 10 seconds after the
ignition was switched on (key switch (5) in position “1”).
5 Temperature indicator (LED) This indicator comes on if the engine is overheating.
Shut down the machine immediately when this indicator
comes on. The engine is shut down automatically 3 minutes
after the indicator comes on.
6 Air lter indicator (LED) This indicator comes on in case of heavy fouling of the air lter.
Shut down the machine immediately when this indicator comes
on. The engine is shut down automatically 10 minutes after
the indicator comes on.
7 Maintenance indicator (LED) This indicator comes on 10 operating hours before the next
scheduled maintenance interval.
Figure 3
