10 SRV 590
Technical data
SRV 590
Noise emissions in accordance with 2000/14/EC
Sound pressure level L
PA
ascertained in accordance
with EN 500, in dB (A)
98
Sound power level L
PA
ascertained in accordance with
EN ISO 3744 and EN 500, in dB (A)
108
Vibration values
Root-mean-square acceleration value for hand-arm
vibration ascertained in accordance with EN 500 in m/
s²
6,9
In accordance with directive 2006/42/EC,
complying with the vibration values is
the owner‘s responsibility.
SRV 590
Weight
Operating weight CECE in kg 62
Dimensions
Overall length in (in mm) 740
Overall width in (in mm) 350
Height (in mm) 1035
Tamping foot width (in mm) 280
Impact rate (/min) 700
Stroke (in mm) 61,6
Drive
Engine manufacturer Honda
Type GXR 120
Performance at operating speed in accordance with
ISO 3046-1 (kW)
2,6
Combustion process 4-stroke gasoline
Operating speed (1/min) 4100
Fuel
Gasoline
unleaded
