Weber 3000 Owner's Manual

19
Step 19
Install Flavorizer Bars and Cooking Grates
You will need: five long Flavorizer Bars, eight short
Flavorizer Bars and two cooking grates.
Set the long Flavorizer Bars side to side in the lower
position, then set the short Flavorizer Bars front to back in
the upper position in the cooking box. Figure 22.
Figure 22
The open "U" of the cooking grates goes down. Set the
cooking grates onto the ledges in the cooking box. Figure 23.
Figure 23
Step 20
Install the bottom tray
You will need: bottom tray, catch pan holder, catch pan and
one drip pan.
Figure 25
Figure 24
Figure 26
Bottom tray
Finger grip on front
edge of bottom tray
Finger grip
Front side of catch
pan holder
Hook the ends of the catch pan holder into the hole in the
bottom tray. Figure 25. The front of the catch pan holder
must be on the same side as the finger grip of the
bottom tray.
Slide the bottom tray onto the mounting rails under the
cooking box with finger grip toward you. Figure 26.
CAUTION: Do not line bottom tray with aluminum foil.
It can cause grease fires by trapping the grease and not
allowing grease to flow into the catch pan.
Put the foil drip pan into the catch pan.
Slide the catch pan into the catch pan holder with its finger
grip towards you.

Weber 3000 Specifications

General

Burners	3
Ignition	Electronic
Fuel Type	Propane
BTU Output	30, 000 BTU/hour
Category	Gas Grill
