Weber 38044 - Page 30

30
MAINTENANCE
8. Disconnect all ignition wires from the Ignition Module.
9. Disconnect the Thermocouple from the IR Burner valve.
10. Remove screws from the manifold assembly: (a) Locate the screws
on both sides of the manifold frame.
(b) Remove the screws from manifold frame.
(a )
(a
(b )
(b )
