31
11. Pull manifold assembly out from the manifold frame.
12. Lift and twist the burner assembly slightly, to separate the Crossover
®
tube (a) from the burners (b).
13. Remove the Crossover
®
tube.
14. Pull the selected burner(s) tube(s) from manifold frame and replace
with a new burner tube.
15. To reinstall the manifold assembly, reverse steps 7 through 14.
CAUTION: The burner openings (1) must be positioned
properly over the valve orifi ces (2).
Check proper assembly before fastening manifold in place.
WARNING: After reinstalling the gas lines, they should
be leak checked with a soap and water solution before
using the grill. (See, “Check for gas leaks.”)
A
B
B
(2)
(1)
MAINTENANCE
