Weber GENESIS II E-310 Owner's Manual

9
Getting Started
LP Tank Installation &
LeakChecking
Installation Location
The tank is hung onto the tank scale which is located
outside the cabinet base under the right side table.
The shape of the collar assembly (the metal protective
ring around the tank valve) determines one of two
directions in which the tank will correctly hang on the
tank scale (A).
Inspect the Tank
1) Confirm that the tank valve is fully closed. Close by
turning valve clockwise.
2) Confirm that the tank valve is the proper mating
type for the regulator (B).
3) Inspect the tank valve, including the internal rubber
seal for damage or debris (C). If damaged, return
tank to local retailer.
Install The Tank
1) Check that all burner control knobs are in the
o position. Check by pushing in and turning
knobs clockwise.
2) Loosen hand nut and rotate tank lock up(D).
3) Lift tank into position on the tank scale (E).
4) Rotate the tank lock down. Tighten the hand nut.
5) Screw the regulator coupling onto the tank valve,
turning clockwise (F). Hand-tighten only. Using a
wrench could damage the regulator coupling and
could cause a leak. Proceed to “CHECKING FOR
GASLEAKS.”
A
B
C
D
E
F

Weber GENESIS II E-310 Specifications

General

Main Burners	3
Total Cooking Area	669 square inches
Primary Cooking Area	513 square inches
Warming Rack Area	156 square inches
BTU-per-hour Input	39, 000
Dimensions - Lid Open	62"H x 59"W x 31"D
Dimensions - Lid Closed	47"H x 59"W x 29"D
Flavorizer Bars	Stainless steel
Side Tables	2
Tool Hooks	6
Built-in Thermometer	Yes
Open Cart Design	Yes
Grease Management System	Yes
Burner Material	Stainless steel
Fuel Type	Liquid Propane (LP)
Cooking Grates	Porcelain-enameled cast iron
