19
5) Slide the burner assembly out from under the guide screw and
washer(1) in the corners of the cooking box.
6) Lift and twist the burner assembly slightly, to separate the crossover
tube(1) from the burners. Remove the burners from the cooking box.
7) To reinstall the burners, reverse 3) through 7).
CAUTION: The burner openings(1) must be positioned
properly over the valve orifi ces(2).
Check proper assembly before fastening manifold in place.
WARNING: After reinstalling the gas lines, they should
be leak checked with a soap and water solution before
using the barbecue. (See Step: “Check for gas leaks.”)
(1)
(2)
(2)
(1)
CROSSOVER
®
IGNITION SYSTEM OPERATIONS
If the Crossover
®
ignition system fails to ignite the Front burner, light the
Front burner with a match. If the Front burner lights with a match, then check
the Crossover
®
ignition system.
• Check that both the white(1) and black(2) ignition wires are attached
properly.
• Check that the Crossover
®
ignition button pushes the igniter (button)
down, and returns to the up position.
If the Crossover
®
ignition system still fails to light, contact the
Customer Service Representative in your area using the contact
information on our web site. Log onto www.weber.com
®
.
MAINTENANCE
1) (2)
(1)
(2)
GENESIS A & B
GENESIS C
55827 O.G._US_PLUS.indd 19 11/2/05 3:59:12 PM
