Weber GENESIS Owner's Guide

7
GAS INSTRUCTIONS
LEAK CHECK PREPARATION
CHECK THAT ALL BURNER VALVES ARE OFF
Valves are shipped in the OFF position, but you should check to be sure that
they are turned OFF. Check by pushing down and turning clockwise. If they
do not turn, they are off. Proceed to the next step. If they do turn continue
turning them clockwise until they stop, then they are off. Proceed to the next
step.



A
F<?I8E45:B?75
C?4G<AH@5
F<?I8E6:B?76
C?4G<AH@6
REMOVE CONTROL PANEL AND BURNER CONTROL KNOBS
You will need: Phillips screwdriver.
1) Remove control knobs.
SILVER, GOLD AND PLATINUM C MODELS
2a) Unclip side burner from Cookbox Frame.
2) Remove screws with a Phillips screwdriver
3) Pull up igniter button until it sticks in the up position and remove control
panel from grill.
4) Replace control panel when Leak Check is completed.
55827 O.G._US_PLUS.indd 7 11/2/05 3:59:04 PM

Weber GENESIS Specifications

General

Ignition	Electronic
Main Burners	3
Total Cooking Area	669 square inches
Fuel Type	Propane or Natural Gas
BTU-per-hour Input	39, 000 BTU
Side Burner	Yes
Sear Station	Yes
Side Burner BTU	12, 000 BTU
Grill Type	Gas Grill
