Weber SRV 66 - Pre-Start Checks

12 SRV62_66
2.4 Pre-Start Work
- Check to ensure that all safety devices are in place. Check the whole tamper for evident damage (visual check).
- Check all screwed connections for tight seat, retighten them if necessary.
- Check the fuel level, if necessary, add fuel (refer to paragraph 2.4.1).
- Check the engine oil level, if necessary add engine oil (refer to paragraph 2.4.2).
2.4.1 Checking the Fuel Level
- Undo the tank cap (3/2) to open the fuel tank
(3/1).
Caution!
Only fill the tank up with clean fuel, refer to
paragraph 3.4 for quantities and specifications.
- Fill the tank up to the bottom edge of the filler neck (3/
3).
Danger!
Take care that fuel does not come in contact with
hot engine parts. Extinguish all open flames and
do not smoke while filling the tank.
Environment Hazard!
Always wipe up any spilled fuel. Dispose of fuel-
soaked cloth in an environmentally-friendly
manner.
- Firmly close the fuel tank (3/2).
Figure 3
1
2
3
