2.4.2 Checking the Engine Oil Level
Figure 4
Figure 4 a
Figure 5
Figure 6
2.4.2.1 SRV 62
Caution!
The engine oil level must be checked with the tamper
standing horizontally on the ground.
- Pull out the oil filler screw by means of the oil dipstick
(4/1), wipe it off with a clean, non-fluffing cloth and
insert it again.
Caution!
Do not screw down!!(4a)
- Pull out the oil dipstick once again.
Caution!
The oil level must reach up to the top mark
(4a/max).
1
- If required, add engine oil according to paragraph
3.3.1 (refer to paragraph 3.4 for quantities and
specifications).
- Firmly screw the oil dipstick down.
2.4.2.2 SRV 66
Caution!
The engine oil level must be checked with the tamper
standing horizontally on the ground.
- Pull out the oil filler screw by means of the oil dipstick
(6/1), wipe it off with a clean, non-fluffing cloth and
insert it again.
Caution!
Do not screw down!!
- Pull out the oil dipstick once again.
Caution!
The oil level must reach up to the top mark
(5/max).
- If required, add engine oil according to paragraph
3.3.1 (refer to paragraph 3.4 for quantities and
specifications).
- Firmly screw the oil dipstick down.
max.
min.
1
