Weber SRV 66 - Cleaning the Fuel Filter; Adjusting;Replacing the Spark Plug SRV 62;SRV 66

24 SRV62_66
3.3.5 Cleaning the Fuel Filter
1
2
Figure 25
3.3.6 Adjusting/Replacing the Spark Plug SRV
62/SRV 66
- Pull off the spark plug socket (27/1) and undo the spark plug.
- Clean the electrodes (28/1) of the spark plug.
- Measure the air gap, gap: 0.6 - 0.7 mm.
- If necessary, correct the air gap or replace the spark plug.
- Screw the spark plug down and fit the spark plug socket.
Caution!
Use spark plugs with correct thermal value only.
0,6 - 0,7 mm
Figure 26
Figure 28
Figure 27
1
1
2
1
1
2
- Pull the fuel line (25/1) off the fuel cock (25/2).
- Unscrew the fuel cock (26/1) including the fuel filter (26/2) out of
the fuel tank.
- Clean the fuel filter (26/2).
- Install the fuel cock with the fuel filter again in the fuel tank.
Danger to the Environment!
Catch or wipe up any escaping fuel immediately and dispose
of fuel soaked cloth in an environmentally-friendly manner.
