Weber SRV 66 - Changing the Engine Oil SRV 66

22 SRV62_66
- Put the tamper out of operation as described in
paragraph 2.7.
Caution!
Drain off the engine oil at operating
temperature and with the engine in horizontal
position only.
- Put a drain pan under the outlet.
Environment Hazard!
Choose a drain pan having a sufficient capacity
to catch all the used oil. Do not let used oil run
into the soil. Dispose of the collected used oil
in an environmentally-friendly manner (acc.
to statutory pollution control regulations).
Wipe up any oil residues and dispose of the
oil-soaked cloth in an environmentally-friendly
manner.
Danger!
Danger of scalding because of hot oil.
- Undo the oil filler screw/dipstick (20/1).
- Undo the oil drain screw (20/2) and completely
drain the engine oil.
- Screw the oil drain screw (20/2) down again (use a
new gasket).
- Add engine oil filler opening (20/3) according to the
quantity chart (3.4).
- Check the oil quantity by means of the plug/dipstick
(20/1) (refer to paragraph 2.4.1).
- Close the tank with the plug/dipstick (20/1) and
check the system for tightness.
3.3.2 Changing the Engine Oil SRV 66
Figure 20
1
2
3
