10
The control panel is separate from the front panel. The
control panel needs to be removed before the front panel
can be removed. Figure 17.
Figure 16
Figure 17
Burner control knobs
Ignition button
Control
panel
Front
panel
Front edge of the
control panel
Put your fingers under the front edge of the control panel
and lift up and pull evenly toward you. Figure 18 (a).
Pull the front panel up and out of the cooking box
assembly. Figure 19.
Figure 18
(a)
Figure 19
Front Panel
Control Panel
Front panel
Remove control panel and front panel
Take off all 4 burner control knobs. Pull up on the ignition
buttons until they stay in the up position. Figure 16.
WARNING
The gas connections of your Weber Gas
Barbecue have been factory tested.We do
however recommend that you leak check
all gas connections before operating your
Weber Gas Barbecue.
CHECK FOR GAS LEAKS
